PERFECT TEMPERATURE CONTROL
The compressor cooling capacity is continuosly controlled
by an actuator driven partialisation device; this ensures
perfect cooling capacity control and, consequently,
extremely precise water temperature control, a fundamental
requirement in industrial applications
R134A ENVIRONMENTALLY FRIENDLY REFRIGERANT
Phoenix plus features R134a, a chlorine-free, zero ozone
depletion potential (ODP) refrigerant with significant
environmental benefits. R134a’s reduced operating pressures
and temperatures ensure high compression levels with
reduced electrical power consumptions.
ACCESSORIES
Electronic fan speed regulation;
Electronic thermostatic valve;
Pre-coated condensing coils for aggressive atmospheres;
Compressor protection by means of automatic cut-outs;
Antivibration dampers kit;
Replicated remote user terminal kit;
Supervisor kits;
Metal mesh protection filters for condensing coils;
Evaporator antifreeze heater.
QUIET AND POWERFUL
SN and SSN versions feature compressors housed in
acoustically insulated metal compartments clad with sound
absorbing material, combined with reduced fan speeds, anti-
vibration dampers and mufflers. This results in the lowest
sound emission levels on the market.
CLASS A ENERGY EFFICIENCY
As the cost of electricity rises so energy efficiency is becoming
an increasingly critical factor for the operating overheads of
an industrial system. That’s why Phoenix plus is designed
to offer unmatched energy efficiency levels. This has been
achieved thanks to meticulous design and components
selection including, for example, continuous compressor
capacity control and the availability of up to 4 compressors
within independent circuits. The majority of HE models
offer Class A energy efficiency in compliance with EECCAC
norms, which translates to EER values superior to 3.1.
VERSIONS
N - standard;
SN - low noise;
SSN - super-silent (for high ambient temperatures);
HE - high energy efficiency version.
Low ambient temperature version (-20 °C).
HIGH EFFICIENCY EVAPORATORS
The direct expansion shell-and-tube evaporators, optimised
for R134a, are among the most technologically advanced
on the market. Thanks to their construction, and the facility
for periodic maintenance, they provide stable and reliable
operation in even the harshest industrial applications.
All evaporators are protected from freezing by means of
the microprocessor’s antifreeze function and a differential
pressure switch.
ADVANCED MICROPROCESSOR
The powerful 32-byte programmable microprocessor allows
energy efficiency levels to be maximized in all load
conditions. The microprocessor features STATUS CONTROL
design, presenting the user with a full range of information
concerning the status of the various controlled parameters.
Remote interfaceability is assured by means of a GSM
modem and full compatibility with the most widely used
Building Management System (BMS)
|
