The BC converter opens up completely
new possibilities for providing oil-free compressed air. And it does so without
using oil-free compressors or installing expensive downstream treatments. And
one thing is for sure: If users want more dependability and reliability they
will have to dig deeper in their pockets - and more frequently.
When it comes to holding down
up-front operational costs, a converter is ideally suited for the provision of
entirely oil-free compressed air because it costs less than an oil-free
compressor or conventional air treatment systems. And it is dependable too:
Penetration of oil into the compressed air network is absolutely impossible!
No matter if you're using a
cartridge or container system - the converter excels by its high economical
efficiency and maintenance friendly design. Handling expenses are extremely low
because no costly checkups are required. Commonly occurring risks - such as oil
penetration - have been discarded, and frequent replacement of component
elements - such as with filters - have been completely eliminated.
Proper disposal is no problem either
- as a matter of fact, in terms of oil content the condensate is of drinking
water quality*! In the BOGE converter the long hydrocarbon chains of the oil
contained in the compressed air are broken up into harmless carbon dioxide and
water, i.e. substances occurring naturally in the air.
The catalytic converter incorporates
a container with compact granulated pellets through which the compressed air
circulates. This process breaks down and converts both oil droplets and oil
vapours. The condensate that forms afterwards is therefore completely oil-free
and can be disposed of much less expensively and without the need for
additional treatment.
All in all the BOGE converter offers
operational reliability of a level that cannot be attained using conventional
treatment stages. Its expected useful life of 15.000 operating hours is
unparalleled. At the end of this time the container with the catalytic
converter granulate is simply replaced.
For you to work out:
- no filter pressure loss, no filter replacement
- negligibly low energy consumption (approx. 5 watts/m3)
- no costs for disposal (oil-water separator, etc.)
- direct discharge of oil-free condensate (drinking water
quality*)
- absolutely safe to operate (oil penetration
impossible!)
- 15.000 maintenance free operating hours
Applications
- breathing air
- blow air (PET)
- food industry
- pharmaceutical industry
- chemical industry
- electrical industry
- and many more
Flow rate:
1 - 50 m3/min
35 - 1766 cfm
|
